Dimension

AL070

AL095

AL110

AL150

AL190

AL230

AL280

L2

36

55.5

60.5

79

94

115

116

D3

42

61.5

78.5

110

142.5

179

216

D4_h7

47.7

67.3

87.3

118.1

152.8

190

229.2

D5_h7

70

95

110

150

190

230

280

Screw

M3X0.5P

M3X0.5P

M4X0.7P

M5X0.8P

M5X0.8P

M6X1P

M6X1P

W

6

8

8

8

12

12

12

X

60

45

45

45

30

30

30
